M10X1.25 D5 3FL SP PT PLUG TAP-BRT
Item #: YG41T7217435
Brand: YG-1 Cutting Tools
Model #: T7217435
| Product Specifications | |
|---|---|
| Thread Size | M10 × 1.25 |
| Cutting Edge Material | HSS |
| Thread Diameter Size (TDZ) | M10 |
| Applicable Material | Steel | Stainless Steel | Cast Iron | Aluminum / Non-Ferrous Materials |
| Thread Pitch (TP) | 1.25 mm |
| Connection Diameter Machine Side (DCONMS) | 0.381″ |
| Thread Tolerance Class (TCTR) | D5 |
| Thread Cutting Part Length (THL) | 1-1/4″ |
| Usable Length (LU) | 1-1/4″ |
| Flute Helix Angle (FHA) | 0 Degrees |
| Overall Length (OAL) | 2.94″ |
| Cutting Direction (HAND) | Right Hand |
| Chamfer | 4P-5P |
| Measurement Type | Metric |
| Coating | Bright |
| Series/List # | T7217 |
| Flute Count (NOF) | 3 |
