Brand: Seco / Part #: 10127481
Item #: 40067712
Brand: Seco
Model #: 10127481
Product Specifications
| Minimum Cutting Diameter (mm) | 63.00 |
| Maximum Cutting Diameter (mm) | 63.00 |
| Maximum Depth of Cut (mm) | 47.00 |
| Arbor Hole Diameter (mm) | 27.00 |
| Compatible Insert Size Code | SN.U1306; XO.X1605 |
| Maximum Ramping Angle | 1.5 |
| Cutter Style | R220.82 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Lead Angle | 90 |
| Rake | Negative |
| Rake Angle | -18.000 |
| Series | R220.82 |
| Overall Height (Mm - 5 Decimals) | 70.00000 |
| Keyway Width (mm) | 12.40 |
| Hub Diameter (mm) | 59.000 |
| Pitch Type | Normal |
| Maximum RPM | 10500.000 |
| Tool Application | Helical Interpolation; Slotting; Shouldering; Ramping |
| Tool Performance | General Purpose |
| Primary Workpiece Material | Universal |
| Keyway Depth (mm) | 7.00 |
| Number of Adjustable Pockets | 0 |
| ISO Number | R220.82-0063-047-SNXO16.4A |
| Complete Insert Compatibility | SN.U1306; XO.X1605 |
| Toolholder Material | Steel |
| Manufacturers Catalog Number | R220.82-0063-047-SNXO16.4A |
| Coolant Through | Yes |
| Number Of Cutter Inserts | 16 |
| Number Of Flutes | 4 |
