3.5 mm Dia. × 4 mm Shank × 114 mm Flute Length × 148 mm OAL, 25xD, 140 Degrees, Axial Inclined Exit, DIN 6535 HA, Cylindrical Solid Carbide Drill DC160 WJ30EU
Item #: TT107684336
Brand: Walter-Titex
Model #: 7684336
| Product Specifications | |
|---|---|
| Drill Bit Size / Cutting Diameter (DC) | 3.5 mm |
| Cutting Edge Material | Carbide |
| Length Group | 25xD |
| Tool Type | High Performance |
| Coating | TiSiAlCrN / TiAlN |
| Grade | WJ30EU |
| Applicable Material | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | Aluminum / Non-Ferrous Materials |
| Measurement Type | Metric |
| Connection Diameter Machine Side (DCONMS) | 4 mm |
| Series/List # | DC160 |
| Coolant Supply Property (CSP) | Coolant Thru |
| Usable Length (LU) | 108 mm |
| Point Angle (SIG) | 140 Degrees |
| Length Chip Flute (LCF) | 114 mm |
| Functional Length (LF) | 114 mm |
| Overall Length (OAL) | 148 mm |
| Flute Helix Angle (FHA) | 30 Degrees |
| Flute Count (NOF) | 2 |
| Shank Length (LS) | 28 mm |
| Cutting Direction (HAND) | Right Hand |
| Shank Type | Cylindrical |
| Body Material | Carbide |
| Shank Standard | DIN 6535 HA |
