BT40 x ER16M-70mm w/ Mini Nut - Collet Chuck
Item #: TE1216325
Manufacturer: Techniks
Mfg #: 16325
Technical Specifications:
*Brand Name: Techniks *Capacity: ER16M *Chuck Size: BT40 *Collets Included: No *Coolant Supply: Coolant-thru Spindle with Coolant Capable Retention Knob, sold separately *Head Length/Projection: 70mm *Model Number: 16325 *Mount: BT40 *Nut Diameter: 0.87 *Overall Length: 8.08 *Size/Range: .019 - .413 *Spindle Interface: BT40 *Weight: 2.4 lbs *Wrench Number: TE1204622
Description:
*Techniks Collet Chucks are balanced to 25,000 RPM at G2.5 tolerance *They are individually lab tested for accuracy and balance and come with their individual performance report *Techniks holders achieve 0.0001" or less T.I.R. as measured from the taper to the collet pocket *
Shipping Info:
*Actual Weight - 2.4000 *Dimensions - Height: 6.00 Length: 3.00 Width: 3.00
