BT40 x TG100 x 80mm Collet Chuck
Item #: RH2224303R
Manufacturer: Rapidhold
Mfg #: 24303R
Technical Specifications:
*Brand Name: Rapidhold *Collet Style: TG100 *Head Length/Projection: 3.15 *Mount: BT40 *Nose Diameter: 2.36 *Overall Length: 6.53 *Shank Length: 3.38 *Size/Range: .09375 - 1.00 *Type: Collet Chuck *Weight: 2.32 lbs
Description:
*Produced according to AT3 specifications *Tools are made of a high quality alloy steel *Collet seat taper T.I.R. greater than 0.0002" *Through the spindle coolant capability *Dynamically balanced to G6.5 @ 15,000 RPM *All collet chucks are supplied with depth set screws *All balanced tools are supplied with QA certificate
Shipping Info:
*Actual Weight - 2.3200
