Emuge - 1/4-19 G(BSP) TiN Finish Cobalt 3 Flute British Standard Pipe Tap
Item #: 94617107
Brand: Emuge
Model #: C0461000.4036
Features and Benefits
Cobalt is harder than high speed steel and provides better wear resistance. It is commonly used on high tensile alloys.
Titanium Nitride (TiN) is a multi-purpose coating which increases chip flow in softer materials. The heat and hardness resistance allows the tool to run at higher speeds than uncoated tools.
Bottoming chamfers are used for threading blind holes to the bottom. They have 1 to 2 threads.
Product Specifications | |
---|---|
Thread Size | 1/4-19 |
Thread Standard | G(BSP) |
Material | Cobalt |
Finish/Coating | TiN |
Number of Flutes | 3 |
Chamfer | Bottoming |
Overall Length (mm) | 100.00 |
Thread Length (Inch) | 1/2 |
Shank Diameter (mm) | 11 |
Square Size (mm) | 9 |
Series/List | C0461000 |
