Brand: Widia / Part #: 2012307

Brand: Widia / Part #: 2012307


Item #: 99726986
Brand: Widia
Model #: 2012307

Product Specifications

Thread Type Internal
Hand of Holder Right Hand
Compatible Insert Size Code 3
Shank Width/Diameter (mm) 20.00
Toolholder Style NVR
Insert Compatibility LT16NR
Coolant Entry Style Code 0-Without Coolant
Insert Holding Method Screw
Shank Height (mm) 18.00
Shank Length (mm) 180.000
Overall Length (mm) 180.0000
Minimum Bore Diameter (mm) 20.00
Series N/A-VR
Multi-use Tool Yes
Cutting Tool Application Grooving; Chamfering; Threading
Maximum Depth of Cut (mm) 1.50
Adjustable Overhang Yes
Back of Bar to Cutting Edge (mm) 21.50
Center to Cutting Edge (mm) 11.50
Insert Inscribed Circle (Decimal Inch) 0.3750
Insert Inscribed Circle (Inch) 3/8
Insert Inscribed Circle (mm) 9.53
Primary Workpiece Material Code P; S; H; K; M; N; O
Toolholder Material Steel
Insert Thickness (Decimal Inch) 0.1350
Style NVR
Coolant Through No
$150.92
