Brand: Widia / Part #: 5908928

Brand: Widia / Part #: 5908928


Item #: 94091311
Brand: Widia
Model #: 5908928

Product Specifications

Insert Style TNMG
Insert Shape Code T
Insert Size Code 331
Insert Shape Triangle
Coating/Finish AlTiN
Manufacturer Grade WS25PT
Corner Radius (Decimal Inch) 0.0157
Insert Material Carbide
Hole Diameter (Decimal Inch) 0.1500
Maximum Depth of Cut (Decimal Inch) 0.3248
Inscribed Circle (Decimal Inch) 0.3750
Insert Holding Method Clamp
Insert Hand Neutral
Insert Thickness (Decimal Inch) 0.1875
Clearance Code N
Tolerance Code M
Included Angle 60.00
Relief Angle 0.000
Series TNMG
Coating Process PVD
Rake Negative
Wiper Edge No
Insert Length (Decimal Inch) 0.6496
Number Of Cutting Edges 6
Secondary Workpiece Material Stainless Steel; Super-alloys & Titanium
Secondary Workpiece Material Code S; M
Ansi Code TNMG331MS
Iso Code TNMG160404MS
Manufacturers Catalog Number TNMG331MS
Cutting Direction Neutral
Coating Classification PVD
Chip Breaker MS
Style TNMG
Width (Decimal Inch - 4 Decimals) 0.3750
Multi-Use Tool Yes
Full Radius No
Multi-Use Application External Turning; Internal Turning
$11.07
