DNGU 22205 F PR1225, 0.008″ Corner Radius, 1/8″ Thick, 0.276″ Inscribed Circle, MEGACOAT, 55 Degree Diamond, Turning Indexable Insert
Item #: KY90TKE03684
Brand: Kyocera Precision Tools
Model #: TKE03684
| Product Specifications | |
|---|---|
| Applicable Material | Stainless Steel | Super-Alloys / Titanium |
| Tool Type | Turning Insert |
| Application | Copying | External Turning |
| Fixing Hole Diameter (D1) | 0.1417″ |
| Insert Style | DNGU |
| Clearance Angle Major (AN) | 0 Degrees |
| Corner Radius (RE) | 0.008″ |
| Number of Cutting Edges | 4 |
| Insert Size | 22205 |
| Cutting Direction (HAND) | Right Hand |
| Insert Thickness (S) | 1/8″ |
| Chip Breaker Type | F |
| Inscribed Circle Diameter (IC) | 0.276″ |
| Quantity | 10 |
| Insert Included Angle (EPSR) | 55 Degrees |
| Measurement Type | Inch |
| Cutting Edge Material | Carbide |
| Shape | 55° Diamond |
| Coating | MEGACOAT |
| Series/List # | DSSS |
| Grade | PR1225 |
| Model No | 8831938 |
