Brand: Sandvik Coromant / Part #: 8353003

Brand: Sandvik Coromant / Part #: 8353003


Item #: 67700575
Brand: Sandvik Coromant
Model #: 8353003

Product Specifications

Mill Diameter (Inch) 3/4
Corner Radius (Decimal Inch) 0.0600
Coating/Finish TiAlSiN
End Mill Material Solid Carbide
Number Of Flutes 4
Single Or Double End Single
Length of Cut (Inch) 1-5/8
Cutting Direction Right Hand
Coolant Through Yes
Mill Diameter (Decimal Inch) 0.7500
Flute Direction Right Hand
Helix Angle 38
Overall Length (Decimal Inch) 4.3150
Chipbreaker No
End Type Corner Radius
Length Type Standard
Extended Reach No
Shank Type Weldon
Centercutting Yes
Material Removal Type Roughing
Shank Diameter (Inch) 3/4
Minimum Helix Angle 35
Maximum Helix Angle 45
Primary Workpiece Material Stainless Steel
Primary Workpiece Material Code M
Secondary Workpiece Material Super Alloys & Titanium
Secondary Workpiece Material Code S
Series CoroMill? Plura
Material Application Stainless Steel; Superalloys & Titanium
Coating Classification PVD
Helix Style Variable
Manufacturers Catalog Number 2S342-1905-152CMB M2CM
$408.13
