Brand: Widia / Part #: 3632131
Item #: 99721151
Brand: Widia
Model #: 3632131
Product Specifications
| Thread Type | Internal |
| Hand of Holder | Left Hand |
| Shank Width/Diameter (Decimal Inch) | 0.5000 |
| Compatible Insert Size Code | 2 |
| Shank Width/Diameter (Inch) | 1/2 |
| Toolholder Style | NEL |
| Insert Compatibility | N.2R |
| Coolant Entry Style Code | 1-Axial Concentric Entry |
| Insert Holding Method | Clamp |
| Shank Height (Decimal Inch) | 0.0000 |
| Shank Length (Inch) | 8 |
| Shank Length (Decimal Inch) | 8.0000 |
| Overall Length (Inch) | 8 |
| Overall Length (Decimal Inch) | 8.0000 |
| Minimum Bore Diameter (Decimal Inch) | 0.7300 |
| Series | A-NE |
| Multi-use Tool | Yes |
| Cutting Tool Application | Grooving; Chamfering; Threading |
| Maximum Depth of Cut (Decimal Inch) | 0.0720 |
| Adjustable Overhang | Yes |
| Back of Bar to Cutting Edge (Inch) | 11/16 |
| Back of Bar to Cutting Edge (Decimal Inch) | 0.6870 |
| Center to Cutting Edge (Decimal Inch) | 0.4370 |
| Insert Inscribed Circle (Decimal Inch) | 0.2188 |
| Insert Inscribed Circle (Inch) | 7/32 |
| Insert Inscribed Circle (mm) | 5.56 |
| Primary Workpiece Material Code | P; S; H; K; M; N; O |
| Coolant Hole Thread Size (Inch) | 1/16-27 NPT |
| Toolholder Material | Steel |
| Insert Thickness (Decimal Inch) | 0.1500 |
| Style | NEL |
| Coolant Through | Yes |
