Brand: Sandvik Coromant / Part #: 8172035
Item #: 99000820
Brand: Sandvik Coromant
Model #: 8172035
Product Specifications
| Insert Style | MF80 |
| Insert Size Code | 1305 |
| Insert Size | 1305 |
| Insert Material | Carbide |
| Manufacturer Grade | 4330 |
| Inscribed Circle (Decimal Inch) | 0.5118 |
| Inscribed Circle (mm) | 13.00 |
| Corner Radius (Decimal Inch) | 0.0315 |
| Corner Radius (mm) | 0.80 |
| Inscribed Circle Range (Decimal Inch) | 0.5100 - 0.6000 |
| Insert Hand | Right Hand |
| Series | MF80 |
| Coating Process | CVD |
| Hole Diameter (Mm) ( - 0 Decimals) | 4.8000 |
| Hole Diameter (Decimal Inch) | 0.189 |
| Maximum Depth of Cut (Decimal Inch) | 0.3543 |
| Maximum Depth of Cut (mm) | 10.00 |
| Number Of Cutting Edges | 8 |
| Insert Shape | Square |
| Primary Workpiece Material | Steel |
| Primary Workpiece Material Code | P |
| Secondary Workpiece Material | Cast Iron |
| Secondary Workpiece Material Code | K |
| Ansi Code | MF80-130508M-M50 4330 |
| Iso Code | MF80-130508M-M50 4330 |
| Manufacturers Catalog Number | MF80-130508M-M50 4330 |
| Cutter Series Compatibility | MF80-R?Qxx; MF80-AR?Rxx |
| Chip Breaker | M50 |
| Cutting Direction | Right Hand |
| Shape | Square |
| Insert Holding Method | Screw/Clamp |
| Thickness (mm) | 5.0000 |
| Coating/Finish | TiCN/Al2O3/TiN |
| Thickness (Decimal Inch - 4 Decimals) | 0.1969 |
