Brand: Ingersoll Cutting Tools / Part #: 5991224

Brand: Ingersoll Cutting Tools / Part #: 5991224


Item #: 06932370
Brand: Ingersoll Cutting Tools
Model #: 5991224

Product Specifications

Insert Style 22UI
Insert Size Code 22
Insert Material Carbide
Manufacturer Grade TT7010
Thread Type Internal & External
Pitch (mm) 5.50
Thread Standard Metric 60 Degree
Insert Hand Neutral
Included Angle 60.00
Chipbreaker None
Series ISO Metric Regular Type
Coating Process PVD
Inscribed Circle (Inch) 1/2
Corner Radius (Decimal Inch) 0.0140
Rake Positive
Primary Workpiece Material Stainless Steel; Cast Iron; Steel
Primary Workpiece Material Code P; K; M
Secondary Workpiece Material Hard Material; Non-Ferrous Metal; Super-alloys & Titanium
Secondary Workpiece Material Code S; H; N
Ansi Code 22UIRL5.50ISO
Iso Code 22UIRL5.50ISO
Cutting Edge to Theoretical Edge Length (Decimal Inch) 0.433
Face of Insert to Tip Centerline (Decimal Inch) 0.094
Number of Teeth Per Side 1
Cutting Direction Neutral
Coating Classification PVD
Thickness (Decimal Inch - 4 Decimals) 0.1880
Coating/Finish TiCN; TiN
$28.22
