12J1P025085W5R01
Item #: IC523057605
Brand: Ingersoll
Model #: 3057605
| Product Specifications | |
|---|---|
| Cutting Diameter (DC/DCX) | 25 mm |
| Connection Diameter Machine Side (DCONMS) | 25 mm |
| Cutting Diameter (DC) | 25 mm |
| Usable Length (LU) | 85 mm |
| Cutting Item Count (CICT) | 4 |
| Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Depth of Cut Maximum (APMX) | 9 mm |
| Measurement Type | Metric |
| Overall Length (OAL) | 145 mm |
| Body Material | Steel |
| Ramping Angle Maximum (RMPX) | 4.4 Degrees |
| Protruding Length (LPR) | 89 mm |
| Application | | Facing | Helical Interpolation | Rampdown | Shouldering | Slotting | |
