Brand: Eaton Cutler-Hammer / Part #: E50AR1
Item #: 00051326
Brand: Eaton Cutler-Hammer
Model #: E50AR1
Product Specifications
| Actuator Type | Rotary Head |
| Actuator Location | Side |
| Body Material | Zinc |
| Actuator Length (Decimal Inch) | 0.6300 |
| Actuator Length (mm) | 16.00 |
| Contact Form | DPST |
| Contact Configuration | NC |
| Terminal Type | Screw |
| Ingress Protection Rating | IP67 |
| Minimum Operating Temperature | 10 F |
| Maximum Operating Temperature | 200 F |
| Overall Width | 39.00 |
| Overall Width (Decimal Inch - 4 Decimals) | 1.5400 |
| Overall Depth (Mm) | 63.00 |
| Overall Depth (Inch) | 2.4600 |
| Standards | UL Listed; CE; IEC 947-5-1; TUV E9271605E02; CSA Certified |
| Nema Rating | 3S; 1; 13; 3; 4; 4X; 6; 6P |
