![BT40 x ER16 x 360mm Collet Chuck - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/BT_7edd69fb-357f-49b7-a264-a1b056ca6495_1024x1024.png?v=1583234346)
BT40 x ER16 x 360mm Collet Chuck
Item #: GM2088411319
Manufacturer: Rego-Fix
Mfg #: 8841.1319
Technical Specifications:
*Brand Name: Rego-Fix *Collet Style: ER16 *Description: BT40 / ER16 x 360 XL *Gage Length: 360mm *Head Length/Projection: 14.17 *Mount: BT40 *Nose Diameter: 1.11 *Nut Diameter: 1.11 *Spindle Interface: BT40 *Type: Extra Long *Weight: 11.88 lbs
Description:
*Case hardened to 58-62 HRc *Pre-balanced to G2.5 @ 22,000 RPM's *T.I.R. from the collet cavity to the holder taper 0.0001" or better *Lot Numbers for lot traceability *Through the spindle coolant or through the flange version available *BT & CAT+ have Hi-Q clamping nut included *AT3 or beter tapers guaranteed *Superior surface finish at 0.25Ra for better fit and accuracy *Swiss made to ISO 90001 *Big Plus System - Licensed by Big Daishowa
Shipping Info:
*Actual Weight - 11.8800
