![BT50 x ER25 x 160mm H Collet Chuck - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/BT_f40e3ec0-951f-4a38-8f6b-bddf9fc5af02_1024x1024.png?v=1583235185)
BT50 x ER25 x 160mm H Collet Chuck
Item #: GM20415012580
Manufacturer: Rego-Fix
Mfg #: 4150.1258
Technical Specifications:
*Brand Name: Rego-Fix *Collet Style: ER25 *Description: BT50 / ER25 x 160mm H *Head Length/Projection: 6.30 *Mount: BT50 *Nose Diameter: 1.57 *Type: Standard *Wrench Number: 7111.32000
Description:
*Case hardened to 58-62 HRc *Pre-balanced to G2.5 @ 22,000 RPM's *T.I.R. from the collet cavity to the holder taper 0.0001" or better *Lot Numbers for lot traceability *Through the spindle coolant or through the flange version available *BT & CAT+ have Hi-Q clamping nut included *AT3 or beter tapers guaranteed *Superior surface finish at 0.25Ra for better fit and accuracy *Swiss made to ISO 90001 *Big Plus System - Licensed by Big Daishowa
Shipping Info:
*Actual Weight - .2500
