![BT40 x ER20 x 100mm H Collet Chuck - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/BT_c19021f4-a650-4ef7-915d-792b64aa170a_1024x1024.png?v=1583234505)
BT40 x ER20 x 100mm H Collet Chuck
Item #: GM20414012050
Manufacturer: Rego-Fix
Mfg #: 4140.1205
Technical Specifications:
*Brand Name: Rego-Fix *Collet Style: ER20 *Description: BT40 / ER20 x 100mm H *Gage Length: 100mm *Head Length/Projection: 3.93 *Mount: BT40 *Nose Diameter: 1.34 *Nut Diameter: 1.34 *Spindle Interface: BT40 *Type: Standard *Weight: 3.3 lbs *Wrench Number: 7112.20010
Description:
*Case hardened to 58-62 HRc *Pre-balanced to G2.5 @ 22,000 RPM's *T.I.R. from the collet cavity to the holder taper 0.0001" or better *Lot Numbers for lot traceability *Through the spindle coolant or through the flange version available *BT & CAT+ have Hi-Q clamping nut included *AT3 or beter tapers guaranteed *Superior surface finish at 0.25Ra for better fit and accuracy *Swiss made to ISO 90001 *Big Plus System - Licensed by Big Daishowa
Shipping Info:
*Actual Weight - 3.3000
