Emuge - 9/16-12 UNC 2B Bottoming Thread Forming Tap
Item #: 18476614
Brand: Emuge
Model #: CU44Z700.5014
Features and Benefits
Bottoming chamfers are used for threading blind holes to the bottom. They have 1 to 2 threads.
Powdered Metal (PM) is tougher and more cost effective than solid carbide. It is commonly used on highly abrasive materials including high silicon aluminums.
| Product Specifications | |
|---|---|
| Thread Size (Inch) | 9/16-12 |
| Class of Fit | 2B |
| Thread Limit | H6 |
| Chamfer | Bottoming |
| Finish/Coating | TiN-80 |
| Material | Powdered Metal High Speed Steel |
| Overall Length (Decimal Inch) | 4.3310 |
| Thread Standard | UNC |
| Series/List | CU44Z700 |
| Thread Direction | Right Hand |
| Shank Diameter (Decimal Inch) | 0.4290 |
| Through Coolant | Yes |
