CNC Routers; X Axis Travel Length (Decimal Inch): 23.8100; Y Axis Travel Length (Decimal Inch): 24.0100; Z Axis Travel Length (Decimal Inch): 3.9370; Spindle Speed (RPM): 24000.00; Spindle Power (Watts): 800; Rapid Feed Rate (IPM): 150; Rapid Feed Rate (M

CNC Routers; X Axis Travel Length (Decimal Inch): 23.8100; Y Axis Travel Length (Decimal Inch): 24.0100; Z Axis Travel Length (Decimal Inch): 3.9370; Spindle Speed (RPM): 24000.00; Spindle Power (Watts): 800; Rapid Feed Rate (IPM): 150; Rapid Feed Rate (M


Item #: 98339849
Brand: Powermatic
Model #: 1797222

Product Specifications

X Axis Travel Length (Decimal Inch) 23.8100
Y Axis Travel Length (Decimal Inch) 24.0100
Z Axis Travel Length (Decimal Inch) 3.9370
Spindle Speed (RPM) 24000.00
Spindle Power (Watts) 800
Rapid Feed Rate (IPM) 150
Rapid Feed Rate (MPM) 3.81
Resolution +/- .00589 Inches (0.15mm)
Voltage 115
Collet Sizes 1/4 & 1/8 Inches
Controller RichAuto B11 DSP
Gantry Clearance With Spoilboard (Inch) 4.5
Ball Screw Size (mm) 16mm
Gantry Clearance Without Spoilboard (Inch) 5.5
Gantry Bridge Material Aluminum
Amperage 13
Gantry Support Material Aluminum
Base Material Steel
Table Material Aluminum
Overall Height (Decimal Inch - 4 Decimals) 28.0000
Overall Width (Decimal Inch - 4 Decimals) 38.0000
Overall Length (Decimal Inch) 38.0000
Includes 1/4 & 1/8 Inches Collets
$7,041.10
