0.63″ Max Depth, 0.079 to 1.26″ Width, External Left Hand Indexable Grooving/Cutoff Toolholder 4.331″ OAL, Uses SA 24-20\x85 Inserts, HSA Monoblock Toolholder, Through Coolant, Series SA Parting / Grooving

0.63″ Max Depth, 0.079 to 1.26″ Width, External Left Hand Indexable Grooving/Cutoff Toolholder 4.331″ OAL, Uses SA 24-20\x85 Inserts, HSA Monoblock Toolholder, Through Coolant, Series SA Parting / Grooving


Item #: 95418562
Brand: Arno
Model #: 502423

Product Specifications

Internal or External External
Maximum Depth of Cut (Decimal Inch) 0.6300
Maximum Depth of Cut (mm) 16.00
Hand of Holder Left Hand
Maximum Groove Width (Decimal Inch) 1.2600
Minimum Groove Width (Decimal Inch) 0.0790
Minimum Groove Width (mm) 2.01
Toolholder Style HSA Monoblock
Insert Holding Method Screw
Insert Compatibility SA 24-20?
Shank Height (Inch) 5/8
Shank Width/Diameter (Decimal Inch) 0.6300
Series Grooving; SA Parting
Overall Length (Decimal Inch) 4.3310
Head Length (Decimal Inch) 0.6300
Manufacturers Catalog Number HSA 1616A-L-SA2402-32-ACS2-.625
Coolant Through Yes
$402.13
