![Heli-Coil - Single Insert, M16x2 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 9-3/4 Free Coils, 24mm Overall Length, 18.9 to 19.6mm Outside Diameter, with Tang, Bright Finish - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/9526204-23_1024x1024.jpg?v=1586461087)
Heli-Coil - Single Insert, M16x2 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 9-3/4 Free Coils, 24mm Overall Length, 18.9 to 19.6mm Outside Diameter, with Tang, Bright Finish
Item #: 95262044
Brand: Heli-Coil
Model #: A4184-16CN240
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M16x2.00 |
Overall Insert Length (mm) | 24.00 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 1 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 18.90 |
Maximum Outside Diameter (mm) | 19.60 |
Finish/Coating | Bright |
Number of Free Coils | 9-3/4 |
Maximum Locking Torque (N/m) | 32.00 |
Minimum Break Away Torque (N/m) | 4.2000 |
Thread Standard | Metric Coarse |
