Recoil - 5/16-24 UNF, 1-1/2D, Stainless Steel Screw Locking Insert - 8-7/8 Free Coils, 15/32 Inch Overall Length, 0.38 to 0.4 Inch Outside Diameter, with Tang, Bright Finish - Exact Industrial Supply

Recoil - 5/16-24 UNF, 1-1/2D, Stainless Steel Screw Locking Insert - 8-7/8 Free Coils, 15/32 Inch Overall Length, 0.38 to 0.4 Inch Outside Diameter, with Tang, Bright Finish


Item #: 94324225
Brand: Recoil
Model #: 14053
Exact Tooling IR#: 04

Product Specifications
Thread Size 5/16-24
Overall Insert Length (Decimal Inch) 0.4690
Tang Yes
Tang Tangless
Length to Diameter Ratio 1-1/2D
Length to Diameter Ratio 1-1/2D
Material Stainless Steel
Minimum Outside Diameter (Decimal Inch) 0.3800
Maximum Outside Diameter (Decimal Inch) 0.4000
Finish/Coating Bright
Number of Free Coils 8-7/8
Maximum Locking Torque (In/Lb) 60
Minimum Break Away Torque (In/Lb) 6.50
Thread Standard UNF
$1.21
