Recoil - 1/4-28 UNF, 1D, Stainless Steel Screw Locking Insert - 5 Free Coils, 1/4 Inch Overall Length, 0.306 to 0.326 Inch Outside Diameter, with Tang, Bright Finish
Item #: 94324209
Brand: Recoil
Model #: 14042
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 1/4-28 |
Overall Insert Length (Decimal Inch) | 0.2500 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1D |
Length to Diameter Ratio | 1D |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.3060 |
Maximum Outside Diameter (Decimal Inch) | 0.3260 |
Finish/Coating | Bright |
Number of Free Coils | 5 |
Maximum Locking Torque (In/Lb) | 30 |
Minimum Break Away Torque (In/Lb) | 3.50 |
Thread Standard | UNF |
