Iscar - 80mm Cut Diam, 27mm Arbor Hole, 6.5mm Max Depth of Cut, 45° Indexable Chamfer & Angle Face Mill - 6 Inserts, SE.. 1203 Insert, Right Hand Cut, 6 Flutes, Series IscarMill
Item #: 93341477
Brand: Iscar
Model #: 3100051
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 80.00 |
| Cutting Diameter (Decimal Inch) | 3.1496 |
| Arbor Hole Diameter (mm) | 27.00 |
| Arbor Hole Diameter (Decimal Inch) | 1.0630 |
| Lead Angle | 45 |
| Overall Height (Decimal Inch) | 1.9685 |
| Overall Height (mm) | 50.00 |
| Insert Compatibility | SE.. 1203 |
| Series | IscarMill |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 6.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.2559 |
| Number of Cutter Inserts | 6 |
| Insert Holding Method | Screw |
| Cutter Style | F45E |
| Number of Flutes | 6 |
| Keyway Width (mm) | 12.40 |
| Keyway Width (Decimal Inch) | 0.4882 |
| Cutting Direction | Right Hand |
| Cutting Edge Length (Decimal Inch) | 0.3583 |
| Complete Insert Compatibility | SEAN 1203AF-N; SEAN 1203AFTN; SEKN 1203AF-N; SEKN 1203AF-N-42; SEKN 1203AFFN; SEKN 1203AFTN; SEKN 1203AFTN-42; SEKR 1203AF-N-42; SEKR 1203AFN-76; SEKR 1203AFTR-HS |
