Recoil - 100 Inserts, 1/4-28 Metric Coarse, 1-1/2D, Nitronic 60 Stainless Steel Screw Locking Insert - 8-1/4 Free Coils, 3/8 Inch Overall Length, 0.306 to 0.326 Inch Outside Diameter, with Tang
Item #: 91910943
Brand: Recoil
Model #: 14043T
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 1/4-28 |
Overall Insert Length (Decimal Inch) | 0.3750 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 100 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.3060 |
Maximum Outside Diameter (Decimal Inch) | 0.3260 |
Number of Free Coils | 8-1/4 |
Maximum Locking Torque (In/Lb) | 30 |
Minimum Break Away Torque (In/Lb) | 3.50 |
Thread Standard | Metric Coarse |
