Recoil - 100 Inserts, #8-32 UNC, 2D, Nitronic 60 Stainless Steel Screw Locking Insert - 8-3/8 Free Coils, 0.328 Inch Overall Length, 0.205 to 0.22 Inch Outside Diameter, with Tang
Item #: 91910893
Brand: Recoil
Model #: 13584T
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #8-32 |
Overall Insert Length (Decimal Inch) | 0.3280 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Length to Diameter Ratio | 2D |
Number of Inserts | 100 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.2050 |
Maximum Outside Diameter (Decimal Inch) | 0.2200 |
Number of Free Coils | 8-3/8 |
Maximum Locking Torque (In/Lb) | 9 |
Minimum Break Away Torque (In/Lb) | 1.50 |
Thread Standard | UNC |
