Recoil - 100 Inserts, #6-32 UNC, 1D, Nitronic 60 Stainless Steel Screw Locking Insert - 2-3/4 Free Coils, 0.138 Inch Overall Length, 0.178 to 0.193 Inch Outside Diameter, with Tang
Item #: 91910844
Brand: Recoil
Model #: 13562T
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #6-32 |
Overall Insert Length (Decimal Inch) | 0.1380 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1D |
Length to Diameter Ratio | 1D |
Number of Inserts | 100 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.1780 |
Maximum Outside Diameter (Decimal Inch) | 0.1930 |
Number of Free Coils | 2-3/4 |
Maximum Locking Torque (In/Lb) | 6 |
Minimum Break Away Torque (In/Lb) | 1.00 |
Thread Standard | UNC |
