![Recoil - M10x1.5 Metric Coarse, 1D, Stainless Steel Screw Locking Insert - 4-7/8 Free Coils, 10mm Overall Length, 11.95 to 12.5mm Outside Diameter, with Tang, Dry Film Lubricant - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/9190677-11_3ff4aa32-c09f-4a01-9f10-12d5052c71a1_1024x1024.jpg?v=1586461045)
Recoil - M10x1.5 Metric Coarse, 1D, Stainless Steel Screw Locking Insert - 4-7/8 Free Coils, 10mm Overall Length, 11.95 to 12.5mm Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91908764
Brand: Recoil
Model #: 15102MAD
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M10x1.50 |
Overall Insert Length (mm) | 10.00 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1D |
Length to Diameter Ratio | 1D |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 11.95 |
Maximum Outside Diameter (mm) | 12.50 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 4-7/8 |
Maximum Locking Torque (N/m) | 6.00 |
Minimum Break Away Torque (N/m) | 0.8000 |
Thread Standard | Metric Coarse |
