Recoil - M8x1.25 Metric Coarse, 1D, Stainless Steel Screw Locking Insert - 4-1/2 Free Coils, 8mm Overall Length, 9.8 to 10.35mm Outside Diameter, with Tang, Dry Film Lubricant - Exact Industrial Supply

Recoil - M8x1.25 Metric Coarse, 1D, Stainless Steel Screw Locking Insert - 4-1/2 Free Coils, 8mm Overall Length, 9.8 to 10.35mm Outside Diameter, with Tang, Dry Film Lubricant


Item #: 91908715
Brand: Recoil
Model #: 15082MAD
Exact Tooling IR#: 04

Product Specifications
Thread Size M8x1.25
Overall Insert Length (mm) 8.00
Tang Yes
Tang Tangless
Length to Diameter Ratio 1D
Length to Diameter Ratio 1D
Material Stainless Steel
Minimum Outside Diameter (mm) 9.80
Maximum Outside Diameter (mm) 10.35
Finish/Coating Dry Film Lubricant
Number of Free Coils 4-1/2
Maximum Locking Torque (N/m) 6.00
Minimum Break Away Torque (N/m) 0.8000
Thread Standard Metric Coarse
$2.66
