Recoil - M6x1 Metric Coarse, 1D, Stainless Steel Screw Locking Insert - 4 Free Coils, 6mm Overall Length, 7.4 to 7.95mm Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91908616
Brand: Recoil
Model #: 15062MAD
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M6x1.00 |
Overall Insert Length (mm) | 6.00 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1D |
Length to Diameter Ratio | 1D |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 7.40 |
Maximum Outside Diameter (mm) | 7.95 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 4 |
Maximum Locking Torque (N/m) | 3.00 |
Minimum Break Away Torque (N/m) | 0.4000 |
Thread Standard | Metric Coarse |
