Recoil - M5x0.8 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 6-7/8 Free Coils, 7.5mm Overall Length, 6.25 to 6.8mm Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91908582
Brand: Recoil
Model #: 15053MAD
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M5x0.80 |
| Overall Insert Length (mm) | 7.50 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 1-1/2D |
| Length to Diameter Ratio | 1-1/2D |
| Material | Stainless Steel |
| Minimum Outside Diameter (mm) | 6.25 |
| Maximum Outside Diameter (mm) | 6.80 |
| Finish/Coating | Dry Film Lubricant |
| Number of Free Coils | 6-7/8 |
| Maximum Locking Torque (N/m) | 1.60 |
| Minimum Break Away Torque (N/m) | 0.3000 |
| Thread Standard | Metric Coarse |
