Recoil - 100 Inserts, M3x0.5 Metric Coarse, 2D, Stainless Steel Screw Locking Insert - 8-3/4 Free Coils, 6mm Overall Length, 3.8 to 4.35mm Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91908483
Brand: Recoil
Model #: 15034MAD
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | M3x0.50 |
Overall Insert Length (mm) | 6.00 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Length to Diameter Ratio | 2D |
Number of Inserts | 100 |
Material | Stainless Steel |
Minimum Outside Diameter (mm) | 3.80 |
Maximum Outside Diameter (mm) | 4.35 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 8-3/4 |
Maximum Locking Torque (N/m) | 0.45 |
Minimum Break Away Torque (N/m) | 0.1000 |
Thread Standard | Metric Coarse |
