Recoil - 100 Inserts, M3x0.5 Metric Coarse, 1-1/2D, Stainless Steel Screw Locking Insert - 6-3/8 Free Coils, 4.5mm Overall Length, 3.8 to 4.35mm Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91908467
Brand: Recoil
Model #: 15033MAD
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | M3x0.50 |
| Overall Insert Length (mm) | 4.50 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 1-1/2D |
| Length to Diameter Ratio | 1-1/2D |
| Number of Inserts | 100 |
| Material | Stainless Steel |
| Minimum Outside Diameter (mm) | 3.80 |
| Maximum Outside Diameter (mm) | 4.35 |
| Finish/Coating | Dry Film Lubricant |
| Number of Free Coils | 6-3/8 |
| Maximum Locking Torque (N/m) | 0.45 |
| Minimum Break Away Torque (N/m) | 0.1000 |
| Thread Standard | Metric Coarse |
