Recoil - #10-32 UNF, 2-1/2D, Stainless Steel Screw Locking Insert - 12 Free Coils, 0.475 Inch Overall Length, 0.236 to 0.256 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91908350
Brand: Recoil
Model #: 14605
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | #10-32 |
| Overall Insert Length (Decimal Inch) | 0.4750 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 2-1/2D |
| Length to Diameter Ratio | 2-1/2D |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.2360 |
| Maximum Outside Diameter (Decimal Inch) | 0.2560 |
| Finish/Coating | Bright |
| Number of Free Coils | 12 |
| Maximum Locking Torque (In/Lb) | 13 |
| Minimum Break Away Torque (In/Lb) | 2.00 |
| Thread Standard | UNF |
