Recoil - #6-40 UNF, 1-1/2D, Stainless Steel Screw Locking Insert - 6 Free Coils, 0.207 Inch Overall Length, 0.173 to 0.193 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91908202
Brand: Recoil
Model #: 14563
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | #6-40 |
| Overall Insert Length (Decimal Inch) | 0.2070 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 1-1/2D |
| Length to Diameter Ratio | 1-1/2D |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.1730 |
| Maximum Outside Diameter (Decimal Inch) | 0.1930 |
| Finish/Coating | Bright |
| Number of Free Coils | 6 |
| Maximum Locking Torque (In/Lb) | 6 |
| Minimum Break Away Torque (In/Lb) | 1.00 |
| Thread Standard | UNF |
