Recoil - #6-40 UNF, 1D, Stainless Steel Screw Locking Insert - 3-1/2 Free Coils, 0.138 Inch Overall Length, 0.173 to 0.193 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91908186
Brand: Recoil
Model #: 14562
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | #6-40 |
| Overall Insert Length (Decimal Inch) | 0.1380 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 1D |
| Length to Diameter Ratio | 1D |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.1730 |
| Maximum Outside Diameter (Decimal Inch) | 0.1930 |
| Finish/Coating | Bright |
| Number of Free Coils | 3-1/2 |
| Maximum Locking Torque (In/Lb) | 6 |
| Minimum Break Away Torque (In/Lb) | 1.00 |
| Thread Standard | UNF |
