Recoil - 1/2-20 UNF, 1-1/2D, Stainless Steel Screw Locking Insert - 12-3/8 Free Coils, 3/4 Inch Overall Length, 0.592 to 0.617 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91908111
Brand: Recoil
Model #: 14083
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 1/2-20 |
Overall Insert Length (Decimal Inch) | 0.7500 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Length to Diameter Ratio | 1-1/2D |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.5920 |
Maximum Outside Diameter (Decimal Inch) | 0.6170 |
Finish/Coating | Bright |
Number of Free Coils | 12-3/8 |
Maximum Locking Torque (In/Lb) | 150 |
Minimum Break Away Torque (In/Lb) | 18.00 |
Thread Standard | UNF |
