Recoil - 7/16-20 UNF, 2D, Stainless Steel Screw Locking Insert - 14-5/8 Free Coils, 7/8 Inch Overall Length, 0.524 to 0.549 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91908079
Brand: Recoil
Model #: 14074
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | 7/16-20 |
| Overall Insert Length (Decimal Inch) | 0.8750 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 2D |
| Length to Diameter Ratio | 2D |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.5240 |
| Maximum Outside Diameter (Decimal Inch) | 0.5490 |
| Finish/Coating | Bright |
| Number of Free Coils | 14-5/8 |
| Maximum Locking Torque (In/Lb) | 100 |
| Minimum Break Away Torque (In/Lb) | 14.00 |
| Thread Standard | UNF |
