Recoil - 7/16-20 UNF, 1-1/2D, Stainless Steel Screw Locking Insert - 10-5/8 Free Coils, 0.656 Inch Overall Length, 0.524 to 0.549 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91908053
Brand: Recoil
Model #: 14073
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 7/16-20 |
Overall Insert Length (Decimal Inch) | 0.6560 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Length to Diameter Ratio | 1-1/2D |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.5240 |
Maximum Outside Diameter (Decimal Inch) | 0.5490 |
Finish/Coating | Bright |
Number of Free Coils | 10-5/8 |
Maximum Locking Torque (In/Lb) | 100 |
Minimum Break Away Torque (In/Lb) | 14.00 |
Thread Standard | UNF |
