Recoil - 3/8-24 UNF, 1-1/2D, Stainless Steel Screw Locking Insert - 11 Free Coils, 9/16 Inch Overall Length, 0.448 to 0.468 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91907964
Brand: Recoil
Model #: 14063
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | 3/8-24 |
| Overall Insert Length (Decimal Inch) | 0.5620 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 1-1/2D |
| Length to Diameter Ratio | 1-1/2D |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.4480 |
| Maximum Outside Diameter (Decimal Inch) | 0.4680 |
| Finish/Coating | Bright |
| Number of Free Coils | 11 |
| Maximum Locking Torque (In/Lb) | 80 |
| Minimum Break Away Torque (In/Lb) | 9.50 |
| Thread Standard | UNF |
