Recoil - 100 Inserts, 5/16-24 UNC, 2D, Stainless Steel Screw Locking Insert - 11-3/8 Free Coils, 5/8 Inch Overall Length, 0.38 to 0.4 Inch Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91907931
Brand: Recoil
Model #: 14054D
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 5/16-24 |
Overall Insert Length (Decimal Inch) | 0.6250 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Length to Diameter Ratio | 2D |
Number of Inserts | 100 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.3800 |
Maximum Outside Diameter (Decimal Inch) | 0.4000 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 11-3/8 |
Maximum Locking Torque (In/Lb) | 60 |
Minimum Break Away Torque (In/Lb) | 6.50 |
Thread Standard | UNC |
