Recoil - 100 Inserts, 1/4-28 UNF, 3D, Stainless Steel Screw Locking Insert - 17-5/8 Free Coils, 3/4 Inch Overall Length, 0.306 to 0.326 Inch Outside Diameter, with Tang, Dry Film Lubricant - Exact Industrial Supply

Recoil - 100 Inserts, 1/4-28 UNF, 3D, Stainless Steel Screw Locking Insert - 17-5/8 Free Coils, 3/4 Inch Overall Length, 0.306 to 0.326 Inch Outside Diameter, with Tang, Dry Film Lubricant


Item #: 91907899
Brand: Recoil
Model #: 14046D
Exact Tooling IR#: 04

Product Specifications
Thread Size 1/4-28
Overall Insert Length (Decimal Inch) 0.7500
Tang Yes
Tang Tangless
Length to Diameter Ratio 3D
Length to Diameter Ratio 3D
Number of Inserts 100
Material Stainless Steel
Minimum Outside Diameter (Decimal Inch) 0.3060
Maximum Outside Diameter (Decimal Inch) 0.3260
Finish/Coating Dry Film Lubricant
Number of Free Coils 17-5/8
Maximum Locking Torque (In/Lb) 30
Minimum Break Away Torque (In/Lb) 3.50
Thread Standard UNF
$1.21
