![Recoil - 1/4-28 UNF, 3D, Stainless Steel Screw Locking Insert - 17-5/8 Free Coils, 3/4 Inch Overall Length, 0.306 to 0.326 Inch Outside Diameter, with Tang, Bright Finish - Exact Industrial Supply](http://exactindustrialsupply.com/cdn/shop/products/9190677-11_0d00e70b-1032-4d3b-b0b3-700b066b9300_1024x1024.jpg?v=1586461832)
Recoil - 1/4-28 UNF, 3D, Stainless Steel Screw Locking Insert - 17-5/8 Free Coils, 3/4 Inch Overall Length, 0.306 to 0.326 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91907881
Brand: Recoil
Model #: 14046
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 1/4-28 |
Overall Insert Length (Decimal Inch) | 0.7500 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 3D |
Length to Diameter Ratio | 3D |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.3060 |
Maximum Outside Diameter (Decimal Inch) | 0.3260 |
Finish/Coating | Bright |
Number of Free Coils | 17-5/8 |
Maximum Locking Torque (In/Lb) | 30 |
Minimum Break Away Torque (In/Lb) | 3.50 |
Thread Standard | UNF |
