Recoil - 100 Inserts, 1/4-28 UNF, 2D, Stainless Steel Screw Locking Insert - 11-3/8 Free Coils, 1/2 Inch Overall Length, 0.306 to 0.326 Inch Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91907857
Brand: Recoil
Model #: 14044D
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | 1/4-28 |
Overall Insert Length (Decimal Inch) | 0.5000 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Length to Diameter Ratio | 2D |
Number of Inserts | 100 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.3060 |
Maximum Outside Diameter (Decimal Inch) | 0.3260 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 11-3/8 |
Maximum Locking Torque (In/Lb) | 30 |
Minimum Break Away Torque (In/Lb) | 3.50 |
Thread Standard | UNF |
