Recoil - 100 Inserts, #10-24 UNC, 3D, Stainless Steel Screw Locking Insert - 11-3/8 Free Coils, 0.57 Inch Overall Length, 0.244 to 0.259 Inch Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91907808
Brand: Recoil
Model #: 13606D
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | #10-24 |
| Overall Insert Length (Decimal Inch) | 0.5700 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 3D |
| Length to Diameter Ratio | 3D |
| Number of Inserts | 100 |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.2440 |
| Maximum Outside Diameter (Decimal Inch) | 0.2590 |
| Finish/Coating | Dry Film Lubricant |
| Number of Free Coils | 11-3/8 |
| Maximum Locking Torque (In/Lb) | 13 |
| Minimum Break Away Torque (In/Lb) | 2.00 |
| Thread Standard | UNC |
