Recoil - #8-32 UNC, 2-1/2D, Stainless Steel Screw Locking Insert - 10-3/4 Free Coils, 0.41 Inch Overall Length, 0.205 to 0.22 Inch Outside Diameter, with Tang, Bright Finish
Item #: 91907675
Brand: Recoil
Model #: 13585
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | #8-32 |
| Overall Insert Length (Decimal Inch) | 0.4100 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 2-1/2D |
| Length to Diameter Ratio | 2-1/2D |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.2050 |
| Maximum Outside Diameter (Decimal Inch) | 0.2200 |
| Finish/Coating | Bright |
| Number of Free Coils | 10-3/4 |
| Maximum Locking Torque (In/Lb) | 9 |
| Minimum Break Away Torque (In/Lb) | 1.50 |
| Thread Standard | UNC |
