Recoil - 100 Inserts, #6-32 UNC, 2D, Stainless Steel Screw Locking Insert - 6-7/8 Free Coils, 0.276 Inch Overall Length, 0.178 to 0.193 Inch Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91907592
Brand: Recoil
Model #: 13564D
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #6-32 |
Overall Insert Length (Decimal Inch) | 0.2760 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 2D |
Length to Diameter Ratio | 2D |
Number of Inserts | 100 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.1780 |
Maximum Outside Diameter (Decimal Inch) | 0.1930 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 6-7/8 |
Maximum Locking Torque (In/Lb) | 6 |
Minimum Break Away Torque (In/Lb) | 1.00 |
Thread Standard | UNC |
