Recoil - 100 Inserts, #5-40 UNC, 1-1/2D, Stainless Steel Screw Locking Insert - 5-1/2 Free Coils, 3/16 Inch Overall Length, 0.158 to 0.173 Inch Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91907527
Brand: Recoil
Model #: 13553D
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Thread Size | #5-40 |
Overall Insert Length (Decimal Inch) | 0.1880 |
Tang | Yes |
Tang | Tangless |
Length to Diameter Ratio | 1-1/2D |
Length to Diameter Ratio | 1-1/2D |
Number of Inserts | 100 |
Material | Stainless Steel |
Minimum Outside Diameter (Decimal Inch) | 0.1580 |
Maximum Outside Diameter (Decimal Inch) | 0.1730 |
Finish/Coating | Dry Film Lubricant |
Number of Free Coils | 5-1/2 |
Maximum Locking Torque (oz-in) | 75 |
Mininum Break Away Torque (oz-in) | 13.00 |
Thread Standard | UNC |
