Recoil - 100 Inserts, #4-40 UNF, 3D, Stainless Steel Screw Locking Insert - 10-7/8 Free Coils, 0.336 Inch Overall Length, 0.144 to 0.159 Inch Outside Diameter, with Tang, Dry Film Lubricant
Item #: 91907485
Brand: Recoil
Model #: 13546D
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Size | #4-40 |
| Overall Insert Length (Decimal Inch) | 0.3360 |
| Tang | Yes |
| Tang | Tangless |
| Length to Diameter Ratio | 3D |
| Length to Diameter Ratio | 3D |
| Number of Inserts | 100 |
| Material | Stainless Steel |
| Minimum Outside Diameter (Decimal Inch) | 0.1440 |
| Maximum Outside Diameter (Decimal Inch) | 0.1590 |
| Finish/Coating | Dry Film Lubricant |
| Number of Free Coils | 10-7/8 |
| Maximum Locking Torque (oz-in) | 48 |
| Mininum Break Away Torque (oz-in) | 10.00 |
| Thread Standard | UNF |
